IRF-S系列硫化物非线性中红外光纤（1.5-6.5um）
- IRflex’s IRF-S Series mid-wave infrared
(MWIR) fiber, made from extra high
purity chalcogenide glass As2S3, is
specially designed and manufactured
to generate and/or guide mid-infrared
wavelengths from 1.5 to 6.5µm with
high transmission efficiency and
nonlinearities about 100 times that of
silica glass fiber.
Applications：
Mid-IR laser beam delivery、IR spectroscopy
Chemical sensing、Scientific and medical
diagnostics IR-imaging system
Nonlinear supercontinnum generation
Infrared countermeasure (IRCM)
Benefits：
Extra low loss, 0.05dB/m @2.8µm
High power handling strength,
tested in house, 6.9W CW in a 9µm core
diameter fiber for 30 minutes without
damage or degradation
High mechanical flexibility
